About Protocol
Introduction
The Throttr Server, including the SDK's, implements a binary protocol on their codes. The protocol defines all the request types and responses in order to make transactions efficient and well-known.
All the source code is available under the official GitHub repository
Definitions
If you want to understand the logic behind the scene, and you're developer or architect, then, this documentation is great for you because it explains byte per byte how Throttr message protocol works.
To start that process, I consider absolutely necessary talk about some concepts first.
Time to Live (TTL)
Is a period of time computed from the now() function of the server plus the amount units on the respective time system used. During that period, the resource attached to the TTL can be considered as valid.
In example; a TTL of 60 seconds will be marked as expired and removed by the scheduler after a minute.
TTL Types
Is the time unit system used to measure the TTL on the record.
The implemented types are:
| Name | Binary |
|---|---|
| Nanoseconds | 0x01 |
| Microseconds | 0x02 |
| Milliseconds | 0x03 |
| Seconds | 0x04 |
| Minutes | 0x05 |
| Hours | 0x06 |
Record
Is an in-memory system entity, identify by a key. It can be a counter or buffer.
Records are designed to expire in some time point. That point is established when the record is created and modified during TTL's updates.
Key
Is a unique value to identify the record in the system. His value is stored in a binary container and comparable using hashing. You can define the keys that fit with your use cases.
Maximum Values
The protocol defines a numeric limit to all operations and it must be selected to fit with the use case.
To understand this dimension, consider Quota as X, TTL as Y and Buffer as Z.
Then:
- To length of
Zand value ofXandY:- Lower than
255then useuint8. - Lower than
65.535then useuint16. - Lower than
4.294.967.295then useuint32. - Lower than
2^64 - 1then useuint64.
- Lower than
Why is so important?
Because if you choose the optimal variant, you'll reduce the RAM and Bandwidth used by the server and clients. If your cases can be solved by uint8 then, using uint64, you'll be wasting 7 bytes per dynamic field.
Dynamic Value Size
The dynamic size (N) is the variable quantity of bytes who are used on dynamic fields, previously described to store and transmit data. So:
| Variant | Length |
|---|---|
| uint8 | 1 byte |
| uint16 | 2 bytes |
| uint32 | 4 bytes |
| uint64 | 8 bytes |
Endianness
The endianness is the way how multibyte data is stored in memory.
Big Endian stores the most significant byte first, meaning the highest-order byte comes at the lowest memory address.
Little Endian, on the other hand, stores the least significant byte first.
For example, the number 2 represented in two bytes would be stored as:
0x00 0x02in Big Endian0x02 0x00in Little Endian
This order affects how data is interpreted when reading raw bytes in memory or across systems.
Throttr use little endian by default. This reduces the amount of mathematical operations to reorder the data on compatible architecture. Almost all current CPU architecture uses little-endian by default.
Usually, standards of IETF, IEEE and ISO recommend big endian. This protocol doesn't try go against the standard. The protocol tries avoid as possible, the undesired and forced conversion operations, in order to provide less contention.
Request types
Version v7.1.0 supports the following request types:
INSERT
This request can add counters to the memory.
Required fields
Request type
The first byte must be 0x01.
Quota
Is the consumable amount assigned to the key in the time-window. Contained in N bytes.
TTL type
Is the TTL type used by the counter. Contained in 1 byte.
TTL
Is the amount in TTL units applicable to the counter. Contained in N bytes.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
The server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
QUERY
This request can retrieve counters.
Required fields
Request type
The first byte must be 0x02.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
The server, usually, resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
If the status was success, then, it also will include:
| Field | Size |
|---|---|
| QUOTA | N bytes |
| TTL TYPE | 1 byte |
| TTL | N bytes |
UPDATE
This request can modify counters and buffers.
Required fields
Request type
The first byte must be 0x03.
Attribute
Is the field to be modified. Contained in 1 byte.
It can be:
| Attribute | Binary |
|---|---|
| QUOTA | 0x00 |
| TTL | 0x01 |
The
bufferscan only be modified usingTTL.
Change type
Is the change type to be applied. Contained in 1 byte.
It can be:
| Change | Binary |
|---|---|
| PATCH | 0x00 |
| INCREASE | 0x01 |
| DECREASE | 0x02 |
The
DECREASEcan produce0x00as response if the result of the operation overQuotais negative.
Any operation over
TTLwill invoke the procedure to reschedule the expiration timer.
Value
Is the value to be used. Contained in N bytes.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
PURGE
This request can remove counters and buffers.
Required fields
Request type
The first byte must be 0x04.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
SET
This request can add buffers to the memory.
Required fields
Request type
The first byte must be 0x05.
TTL type
Is the TTL type used by the counter. Contained in 1 byte.
TTL
Is the amount in TTL units applicable to the counter. Contained in N bytes.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Size of value
Is the quantity of chars (O) used by the value. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Value
Is the value of the record. Contained in O bytes.
Response
The server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
GET
This request can retrieve buffers.
Required fields
Request type
The first byte must be 0x06.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
The server, usually, resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
If the status was success, then, it also will include:
| Field | Size |
|---|---|
| TTL TYPE | 1 byte |
| TTL | N bytes |
VALUE SIZE (O) | N bytes |
| VALUE | O bytes |
LIST
This request can list counters and buffers.
Required fields
Request type
The first byte must be 0x07.
Response
This server resolve this request, initially, by sending 8 bytes response.
| Field | Size |
|---|---|
| FRAGMENTS (P) | 8 bytes |
After that we receive P fragments in 16 bytes:
| Field | Size |
|---|---|
| FRAGMENT | 8 bytes |
| NUMBER OF SCOPED KEYS (Q) | 8 bytes |
Per Q we are going to receive fixed 11 + N bytes:
| Field | Size |
|---|---|
| KEY SIZE (QL) | 1 byte |
| KEY TYPE | 1 byte |
| TTL TYPE | 1 byte |
| TIME POINT | 8 bytes |
| BYTES USED | N bytes |
Nrepresentvalue_typelength.
At the end of the fragment we are going receive the keys in R bytes (sum of QL):
| Field | Size |
|---|---|
| KEY | QL bytes |
INFO
This request can provide instance related information.
Required fields
Request type
The first byte must be 0x08.
Response
This server resolve this request, initially, by sending 236 bytes response.
| Field | Size |
|---|---|
| TIMESTAMP | 8 bytes |
| TOTAL REQUESTS | 8 bytes |
| REQUESTS PER MINUTE | 8 bytes |
TOTAL INSERT | 8 bytes |
INSERT PER MINUTE | 8 bytes |
TOTAL QUERY | 8 bytes |
QUERY PER MINUTE | 8 bytes |
TOTAL UPDATE | 8 bytes |
UPDATE PER MINUTE | 8 bytes |
TOTAL PURGE | 8 bytes |
PURGE PER MINUTE | 8 bytes |
TOTAL GET | 8 bytes |
GET PER MINUTE | 8 bytes |
TOTAL SET | 8 bytes |
SET PER MINUTE | 8 bytes |
TOTAL LIST | 8 bytes |
LIST PER MINUTE | 8 bytes |
TOTAL INFO | 8 bytes |
INFO PER MINUTE | 8 bytes |
TOTAL STATS | 8 bytes |
STATS PER MINUTE | 8 bytes |
TOTAL STAT | 8 bytes |
STAT PER MINUTE | 8 bytes |
TOTAL SUBSCRIBE | 8 bytes |
SUBSCRIBE PER MINUTE | 8 bytes |
TOTAL UNSUBSCRIBE | 8 bytes |
UNSUBSCRIBE PER MINUTE | 8 bytes |
TOTAL PUBLISH | 8 bytes |
PUBLISH PER MINUTE | 8 bytes |
TOTAL CHANNEL | 8 bytes |
CHANNEL PER MINUTE | 8 bytes |
TOTAL CHANNELS | 8 bytes |
CHANNELS PER MINUTE | 8 bytes |
TOTAL WHOAMI | 8 bytes |
WHOAMI PER MINUTE | 8 bytes |
TOTAL CONNECTION | 8 bytes |
CONNECTION PER MINUTE | 8 bytes |
TOTAL CONNECTIONS | 8 bytes |
CONNECTIONS PER MINUTE | 8 bytes |
| TOTAL READ BYTES | 8 bytes |
| READ BYTES PER MINUTE | 8 bytes |
| TOTAL WRITE BYTES | 8 bytes |
| WRITE BYTES PER MINUTE | 8 bytes |
| TOTAL KEYS | 8 bytes |
| TOTAL COUNTERS | 8 bytes |
| TOTAL BUFFERS | 8 bytes |
| TOTAL ALLOCATED BYTES ON COUNTERS | 8 bytes |
| TOTAL ALLOCATED BYTES ON BUFFERS | 8 bytes |
| TOTAL SUBSCRIPTIONS | 8 bytes |
| TOTAL CHANNELS | 8 bytes |
| RUNNING SINCE | 8 bytes |
| TOTAL CONNECTIONS | 8 bytes |
| VERSION | 16 bytes |
STAT
This request can provide metrics for specific counter or buffer.
Required fields
Request type
The first byte must be 0x09.
Size of key
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Key
Is the key of the record. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
If the byte is 0x01 then will also include 32 bytes more:
| Field | Size |
|---|---|
| READS PER MINUTE | 8 bytes |
| WRITES PER MINUTE | 8 bytes |
| TOTAL READS | 8 bytes |
| TOTAL WRITES | 8 bytes |
STATS
This request can provide metrics of counters and buffers.
Required fields
Request type
The first byte must be 0x10.
Response
This server resolve this request, initially, by sending 8 bytes response.
| Field | Size |
|---|---|
| FRAGMENTS (P) | 8 bytes |
After that we receive P fragments in 16 bytes:
| Field | Size |
|---|---|
| FRAGMENT | 8 bytes |
| NUMBER OF SCOPED KEYS (Q) | 8 bytes |
Per Q we are going to receive fixed 33 bytes:
| Field | Size |
|---|---|
| KEY SIZE (QL) | 1 byte |
| READS PER MINUTE | 8 bytes |
| WRITES PER MINUTE | 8 bytes |
| TOTAL READS | 8 bytes |
| TOTAL WRITES | 8 bytes |
Nrepresentvalue_typelength.
At the end of the fragment we are going receive the keys in R bytes (sum of QL):
| Field | Size |
|---|---|
| KEY | QL bytes |
SUBSCRIBE
This request can start a subscription to a channel.
Required fields
Request type
The first byte must be 0x11.
Size of channel
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Channel
Is the name of the channel. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
UNSUBSCRIBE
This request can finish a subscription to a channel.
Required fields
Request type
The first byte must be 0x12.
Size of channel
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Channel
Is the name of the channel. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
PUBLISH
This request can send a buffer to a subscribed channel.
Required fields
Request type
The first byte must be 0x13.
Size of channel
Is the quantity of chars (M) used by the channel. Contained in 1 byte.
Size of payload
Is the quantity of chars (O) used by the payload. Contained in N bytes.
Channel
Is the name of the channel. Contained in M bytes.
Payload
Is the payload. Contained in O bytes.
Response
This server resolve this request by sending 1 byte response.
The client will receive 0x01 on success or 0x00 on failure.
CONNECTIONS
This request can list connections.
Required fields
Request type
The first byte must be 0x14.
Response
This server resolve this request, initially, by sending 8 bytes response.
| Field | Size |
|---|---|
| FRAGMENTS (P) | 8 bytes |
After that we receive P fragments in 16 bytes:
| Field | Size |
|---|---|
| FRAGMENT | 8 bytes |
| NUMBER OF SCOPED CONNECTIONS (Q) | 8 bytes |
Per Q we are going to receive fixed 235 bytes:
| Field | Size |
|---|---|
| ID | 16 bytes |
| IP VERSION | 1 byte |
| IP | 16 bytes |
| PORT | 2 byte |
| CONNECTED AT | 8 bytes |
| READ BYTES | 8 bytes |
| WRITE BYTES | 8 bytes |
| PUBLISHED BYTES | 8 bytes |
| RECEIVED BYTES | 8 bytes |
| ALLOCATED BYTES | 8 bytes |
| CONSUMED BYTES | 8 bytes |
INSERT REQUESTS | 8 bytes |
SET REQUESTS | 8 bytes |
QUERY REQUESTS | 8 bytes |
GET REQUESTS | 8 bytes |
UPDATE REQUESTS | 8 bytes |
PURGE REQUESTS | 8 bytes |
LIST REQUESTS | 8 bytes |
INFO REQUESTS | 8 bytes |
STAT REQUESTS | 8 bytes |
STATS REQUESTS | 8 bytes |
PUBLISH REQUESTS | 8 bytes |
SUBSCRIBE REQUESTS | 8 bytes |
UNSUBSCRIBE REQUESTS | 8 bytes |
CONNECTIONS REQUESTS | 8 bytes |
CONNECTION REQUESTS | 8 bytes |
CHANNELS REQUESTS | 8 bytes |
CHANNEL REQUESTS | 8 bytes |
WHOAMI REQUESTS | 8 bytes |
CONNECTION
This request can retrieve metadata about specific connection.
Required fields
Request type
The first byte must be 0x15.
Connection index
The index contained in 4 bytes.
Response
This server resolve this request, initially, by sending 1 byte response.
If index exists then will also include fixed 235 bytes:
| Field | Size |
|---|---|
| ID | 16 bytes |
| IP VERSION | 1 byte |
| IP | 16 bytes |
| PORT | 2 byte |
| CONNECTED AT | 8 bytes |
| READ BYTES | 8 bytes |
| WRITE BYTES | 8 bytes |
| PUBLISHED BYTES | 8 bytes |
| RECEIVED BYTES | 8 bytes |
| ALLOCATED BYTES | 8 bytes |
| CONSUMED BYTES | 8 bytes |
INSERT REQUESTS | 8 bytes |
SET REQUESTS | 8 bytes |
QUERY REQUESTS | 8 bytes |
GET REQUESTS | 8 bytes |
UPDATE REQUESTS | 8 bytes |
PURGE REQUESTS | 8 bytes |
LIST REQUESTS | 8 bytes |
INFO REQUESTS | 8 bytes |
STAT REQUESTS | 8 bytes |
STATS REQUESTS | 8 bytes |
PUBLISH REQUESTS | 8 bytes |
SUBSCRIBE REQUESTS | 8 bytes |
UNSUBSCRIBE REQUESTS | 8 bytes |
CONNECTIONS REQUESTS | 8 bytes |
CONNECTION REQUESTS | 8 bytes |
CHANNELS REQUESTS | 8 bytes |
CHANNEL REQUESTS | 8 bytes |
WHOAMI REQUESTS | 8 bytes |
CHANNELS
This request can list channels.
Required fields
Request type
The first byte must be 0x16.
Response
This server resolve this request, initially, by sending 8 bytes response.
| Field | Size |
|---|---|
| FRAGMENTS (P) | 8 bytes |
After that we receive P fragments in 16 bytes:
| Field | Size |
|---|---|
| FRAGMENT | 8 bytes |
| NUMBER OF SCOPED CHANNELS (Q) | 8 bytes |
Per Q we are going to receive fixed 21 bytes:
| Field | Size |
|---|---|
| CHANNEL SIZE (QL) | 1 byte |
| READ BYTES | 8 bytes |
| WRITE BYTES | 8 bytes |
| SUBSCRIBED CONNECTIONS | 4 bytes |
At the end of the fragment we are going receive the keys in R bytes (sum of QL):
| Field | Size |
|---|---|
| CHANNEL | QL bytes |
CHANNEL
This request can provide metrics for specific channel.
Required fields
Request type
The first byte must be 0x17.
Size of channel
Is the quantity of chars (M) used by the key. Contained in 1 byte.
Channel
Is the channel name. Contained in M bytes.
Response
This server resolve this request by sending 1 byte response.
If the byte is 0x01 then will also include 4 bytes more:
| Field | Size |
|---|---|
| NUMBER OF SUBSCRIBERS (Q) | 8 bytes |
Per Q we need to read 28 bytes:
| Field | Size |
|---|---|
| CONNECTION ID | 16 bytes |
| SUBSCRIBED_AT | 8 bytes |
| READ BYTES | 8 bytes |
| WRITE BYTES | 8 bytes |
WHOAMI
This request can provide the index of the current connection.
Required fields
Request type
The first byte must be 0x18.
Response
This server resolve this request, by sending the connection ID in 16 bytes.
